Name: RY HSD Waterproof Connector Wire Harness Hsd4p Male and Female Connector RF High-frequency Coaxial Spiral Video Cable
Brand: Zhangjiagang RY Electronic CO.,LTD
SKU: LD5-101-3000-ZZ
Price: 2.00 USD
Availability: InStock

Ev > Ürünler > Özel tel koşum >

RY HSD Waterproof Connector Wire Harness Hsd4p Male and Female Connector RF High-frequency Coaxial Spiral Video Cable

waterproof RF coaxial cable

HSD4P male female connector

spiral video wire harness

Menşe yeri:

Jiangsu, Çin

Marka adı:

Model numarası:

LD5-101-3000-ZZ

Bize Ulaşın

Bir teklif isteği

RY HSD Waterproof Connector Wire Harness Hsd4p Male and Female Connector RF High-frequency Coaxial Spiral Video Cable

Ürün Detayları

Başvuru:

220.110

Ödeme ve Gönderim Koşulları

Min sipariş miktarı

Fiyat

$2-3

ilgili ürünler

RY HSD Waterproof Connector Wire Harness Hsd4p Male and Female Connector RF High-frequency Coaxial Spiral Video Cable

En İyi Fiyatı Alın

Custom Molex Micro-Fit 3.0 Series 3mm Pitch 10 Circuits 2 Row Male Straight Crimp Connector Molded Cable Wire Harness 430251000

En İyi Fiyatı Alın

RY 8mm 25pcs Solderless LED Tape Light Connector 2 Pin Screw Down Terminal Block Connector Led Connectors for Strip Lights

En İyi Fiyatı Alın

Custom 430251000 MOLEX 10pin 20pin Micro Fit 3.0 Male to Male Straight Crimp Connector Molding Cable Terminal Wire Harness

En İyi Fiyatı Alın

Bize Ulaşın

86--13405295160

info@rygroup.net

Şimdi İletişime Geçin

Ürün Açıklaması

RY HSD Waterproof Connector Wire Harness

HSD4P male and female connector RF high-frequency coaxial spiral video cable designed for reliable performance in demanding industrial applications.

Product Specifications

Body Material	Brass / Zinc Diecast
Body Finish	Matte Tin / Nickel / Tin
Insulator Material	LCP
Signal Contacts	CuZn / CuSn (Brass, Bronze)
Dielectric	PA / LCP
Gasket	Silicone / Rubber
Crimping Ferrule	CuSn (Bronze)
Plastic Housings and Secondary Lock	PA / PBT
Impedance	100 Ω
Frequency Range	DC～6GHz
Voltage Rating	100 VRMS Max Continuous
Dielectric Withstanding Voltage	250 VRMS Min
Insulation Resistance	1000 MΩ Min
Contact Resistance	10 MΩ Max (Center) / 7.5 MΩ Max (Outer)
Temperature Range	−40°C to +105°C
Mating Cycles	25 Min
Coupling Mechanism	Push-On

Product Images

Frequently Asked Questions

When can we get the reply?

Any inquiries will be replied within 24 hours.

Can I get some samples?

Yes, sample order is available for quality check and market test, and it will be freight collect payment.

What's the delivery time?

It usually takes about 1-3 days to produce samples and 3-7 days to produce the products.

What's your payment term?

We usually accept PAYPAL, T/T as the main payment term, and other payments can also be negotiated.

Quality problems?

If there is any quality problem or question, we could offer technical support or return service.

How to contact us?

Send your Inquiry Details in the Below, Click "Send" Now! Free sample and best answers are waiting for you.
